Wylex DSF80M Switch Fuse Isolator Unit 80A Metal Enclosure

Wylex DSF80M 100A domestic switch fuse isolator unit. Housed within a robust all-metal  non-combustible enclosure DSF80M effectively protects and isolates incoming supply. Complying with BS 7671 IET wiring regulations, the metal enclosure is made from 1mm thick steel and is finished with low smoke and fume Epoxy paint.

Wylex DSF80M is designed to streamline installation and connection of sub mains, making system extensions fast and simple. Fitted with a rotating fuse carrier for easy withdrawal, a lockable main switch, and automatic disconnection of the fuse from its holder. DS80M comes complete with a 80 amp BS1361 fuse and is compatible with HRC fuses, making it suitable for many different requirements. DSF80M is built to replace the Wylex 110M/80.

Features of Wylex DSF80M:

• Switch fuse isolator with a metal door and all-metal enclosure
• 80 amp fuse included - 80A BS1361 fuse
• For use in domestic properties
• Live and neutral cable capacity 16mm²-35mm²
• Dual screw terminals throughout
• 16mm Earth termination point inside enclosure
• Low smoke and fume Epoxy paint finish
• 32mm standard cable gland knockout (top and bottom)
• Number of poles: single pole and neutral
• Voltage: 230V
• IP rating: IP20
• Height: 302mm
• Width: 178mm
• Depth: 111mm
• Standards: BS7671 IET, BS EN 61439-3, IEC 60947-3, BS1361, BS7671
