Dimplex Bathroom Fan Heater FX20EIPX4 Pull Cord and Timer IPX4

Dimplex FX20EIPX4 wall mounted downflow electric fan heater, 2kW provides warmth and heat fast a must have for cold bathrooms (if it's too powerful it can be downrated to 1kw on installation for smaller bathrooms). IPX4 rated and therefore ideal for use in the majority of kitchens or ensuites, designed for use in bathroom zones 1 and 2. Operated by a pull cord with convenient over run timer, automatically shuts the unit off after a preset time.

Dimplex FX20EIPX4 replaces the previous Dimplex model number FX20IPX4 (designed with the same footprint for a fast retrofit)

Features of the Dimplex FX20EIPX4

• Fast and easy installation
• Pull cord operated for safe and easy operation
• Use and forget with the 30 minute overrun timer
• Pull the pull cord a second time to switch off before the timer runs out
• 2kW but can be downrated to 1kW on Installation
• IPX4 rated, splashproof for use in Bathroom Zones 1 and 2
• Recommended mounting height: 1.8m minimum
• Heat output from a grille at the base of the heater
• Full safety protection via a thermal fuse
• Fire safe made from flame retardant self extinguishing grade nylon
• Double insulated plastic case
• EcoDesign Lot 20 Compliant
• Cable exit point middle top
• Cable not included

How to Install the Dimplex FX20EIPX4

• Designed to retrofit previous and current models FX20VE, FX20V or FX20IPX4
• Cable entry must be at the top of the unit and not by the grille at the bottom
• Minimum mounting height from the floor is 900mm
• Minimum distance between any shelves or any projecting surfaces is 600mm
• Minimum  distance to the ceiling is 300mm
• For maximum efficiency ensure the air stream is not obstructed
• Wall mounted via three screws (two keyhole and one through the aplicance)
