Hager VME02SPD Consumer Unit Type 2 Surge Protection Modular Kit

Hager VME02SPD type 2 consumer unit surge protection kit is supplied with integrated busbar and patented automatic earth connection to the DIN rail and a 6mm earth cable, provides protection against surges and works in conjuntion with domestic consumer units.

This SPD kit fits within the standard consumer unit. Line and Neutral connections are via 2 pole copper busbar from the SPD to the supply side of the main incoming device terminated within the top of the devices bi-connect, the earth cable will be terminated within the main earth bar within the consumer unit, and terminated in either the left hand or right hand earth terminal at the top of the SPD ensuring connections are tighten to 3.5Nm.

Built with Type 2 surge protection, which limits transient overvoltage due to lightning, switching of transformers, motors and lighting. This ensures protection against downtime and damage of electronic components and materials. Ideal for surge protection of local isolation in homes SPDs are recommended to protect electrical equipment such as white goods, TVs, PCs etc.

Type 2 SPDs prevent overvoltages from spreading in electrical installations. The units come complete with a lifetime indicator and benefit from a 8/20 µs current wave.

Features of Hager VME02SPD Type 2 Consumer Unit Include:

• Type 2 SPD to aid compliance with 18th Edition BS 7671
• Complete with a lifetime indicator - clear = healthy, red = replace
• Number of poles: 1
• Din rail mountable
• Terminal capacity: 50mm tails/ 16mm earth
• Voltage: 230V
• Robust metal construction
• Colour: Grey
• Width: 36mm
• IP rating: IP20
