JCC Skytile LED Panel 38W 600x600mm CCT UGR19 IP40

The JCC Skytile LED Panel 38W 600x600mm is a high-performance solution for offices, education, healthcare and general commercial environments. Delivering up to 109 lumens per circuit watt, this panel provides excellent energy efficiency while maintaining comfortable, evenly distributed illumination across the workspace.

Selectable Colour Temperature with Low Glare Performance

Featuring 3CCT selection (3000K, 4000K and 5700K), the Skytile panel allows installers and specifiers to tailor the light output to suit different applications and environments. Designed with UGR19 glare control to comply with BS EN 12464-1 lighting of workspaces, it helps reduce eye strain and improve visual comfort, making it ideal for screen-based and task-focused areas.

Installer-Focused Design with Long-Term Reliability

An 8-pole loop-in/loop-out, double-hinged driver with permanent live and earth enables fast, continuous wiring on site, while the flicker-free non-dimmable driver ensures stable, comfortable lighting. Meeting TP(a) diffuser requirements and offering a 54,000-hour LED lifespan, the Skytile panel delivers dependable long-term performance backed by a 5-year warranty.

Key features of the JCC Skytile LED Panel 38W 600x600mm CCT UGR19 IP40:

• 38W LED panel, 600x600mm format
• Up to 109 LpcW for excellent efficiency
• 3CCT selectable: 3000K / 4000K / 5700K
• Lumen output: 3700 / 4100 / 3750 lumens
• UGR19 compliant for low-glare workspace lighting
• Meets TP(a) requirements, suitable for all applications
• 8-pole loop-in/loop-out double-hinged driver with permanent live and earth
• Flicker-free, non-dimmable driver supplied as standard
• Available in low, standard and high output versions
• High-output option delivering over 4850 lumens for higher ceilings
• Long 54,000-hour LED lifetime
• IP40 rated for indoor commercial use
• Height: 25mm
• Width: 595mm
• Length: 595mm
• Backed by a 5-year warranty
