Wylex DSF60M 60A Switch Fuse Isolator Unit Metal Enclosure

Wylex DSF60M 100A domestic switch fuse isolator unit. Housed within a robust all-metal  non-combustible enclosure DSF60M effectively protects and isolates incoming supply. Complying with BS 7671 IET wiring regulations, the metal enclosure is made from 1mm thick steel and is finished with low smoke and fume Epoxy paint.

Wylex DSF60M is designed to streamline installation and connection of sub mains, making system extensions fast and simple. Fitted with a rotating fuse carrier for easy withdrawal, a lockable main switch, and automatic disconnection of the fuse from its holder. DS60M comes complete with a 60 amp BS1361 fuse and is compatible with HRC fuses, making it suitable for many different requirements. DSF80M is built to replace the Wylex 160CM.

Features of Wylex DSF60M:

• Switch fuse isolator with a metal door and all-metal enclosure
• 60 amp fuse included - 60A BS1361 fuse
• For use in domestic properties
• Live and neutral cable capacity 16mm²-35mm²
• Dual screw terminals throughout
• 16mm Earth termination point inside enclosure
• Low smoke and fume Epoxy paint finish
• 32mm standard cable gland knockout (top and bottom)
• Number of poles: single pole and neutral
• Voltage: 230V
• IP rating: IP20
• Height: 302mm
• Width: 178mm
• Depth: 111mm
• Standards: BS7671 IET, BS EN 61439-3, IEC 60947-3, BS1361, BS7671
