Collingwood LED Driver 75W 24V 3.13A LSD7524

Collingwood Lighting LSD7524 75W 24V LED Driver converts a 220-240V AC mains supply to a 24V output for compatible low-voltage LED lighting installations. With SELV output, Class II construction and integrated mains surge, short-circuit and open-circuit protection, it provides contractors with a dependable power supply for indoor lighting projects.

75W 24V LED Power Supply

The LSD7524 delivers a rated output of 75W at 24V with a maximum drive current of 3.125A. Its 0.9 power factor supports efficient operation when powering compatible 24V LED products within the driver’s rated load.

Built-In Electrical Protection

Integrated protection against mains surges, short circuits and open circuits helps protect the driver and connected lighting equipment. SELV output and Class II construction provide additional electrical separation for suitably designed low-voltage lighting installations.

Installer-Friendly Terminal Connections

Input and output terminal connections accept 0.75-1.5mm² cable, giving installers a straightforward termination method without pre-fitted leads. The compact polycarbonate enclosure measures 180mm long, 52mm wide and 30mm high, making it suitable for installation in accessible indoor voids and enclosures.

Designed For Long-Term Reliability

The IP20-rated driver operates in ambient temperatures from -15°C to +45°C and has a maximum case temperature of 90°C. A 5-year manufacturer’s warranty provides added reassurance for residential and commercial lighting projects.

Key Features of the Collingwood Lighting 24V LED Driver LSD7524 Include:

• 75W LED Driver For Compatible 24V Lighting Installations
• 220-240V AC Input For Connection To UK Mains Supplies
• 24V Output With A Maximum Drive Current Of 3.125A
• SELV Output Supports Safe Low-Voltage Lighting Installation
• Class II Construction Provides Double-Insulated Electrical Protection
• Mains Surge, Short-Circuit And Open-Circuit Protection
• 0.9 Power Factor Supports Efficient Driver Operation
• Terminal Connections Accept 0.75-1.5mm² Cable
• Polycarbonate Construction For A Lightweight And Durable Enclosure
• IP20 Rating For Indoor Installation
• Operating Temperature: -15°C To +45°C
• Length: 180mm
• Width: 52mm
• Height: 30mm
• Weight: 300g
• Warranty: 5 Years
