Vent-Axia Sentinel Econiq MVHR Medium 499632

Vent-Axia Lo-Carbon Sentinel Econiq M 499632 MVHR Unit is a high efficiency mechanical ventilation with heat recovery system for medium to larger residential projects. Developed and manufactured in the UK, it combines SEC Class A+ performance, smart app control, up to 93% thermal efficiency and flexible vertical or horizontal duct options for professional whole-house ventilation installations.

High Efficiency Heat Recovery

The Sentinel Econiq M uses a high efficiency composite plastic counterflow heat exchanger to recover heat from extracted air before supplying fresh filtered air back into the property. With SAP PCDB recognition and thermal efficiency up to 93%, it supports energy-conscious ventilation for new build and low-energy homes.

Smart App And Wireless Controls

Vent-Axia Connect app control is included as standard, giving users simple smartphone control over ventilation settings. RF868, Wi-Fi and Bluetooth low energy 4.2 connectivity also support wireless sensors, commissioning and flexible control options across the home.

Flexible Installation For Modern Homes

The Econiq M provides a recommended maximum system flow of 125l/s at 150Pa, making it suitable for larger residential layouts. Vertical and horizontal spigot options help installers work around tight plant spaces, while left or right hand orientation can be set through the controls during commissioning.

Better Indoor Air Quality

ISO 60% Coarse (G4) filters are supplied as standard to help remove larger airborne particles from incoming air. Optional ISO ePM10 50% (M5) and ISO ePM2.5 70% (F7) filtration can be specified where higher filtration performance is required.

Key Features of the Vent-Axia Lo-Carbon Sentinel Econiq M 499632 Include:

• SEC Class A+ MVHR Unit For High Efficiency Whole-House Ventilation
• Up To 93% Thermal Efficiency For Energy-Conscious Residential Projects
• Recommended Maximum System Flow Of 125l/s At 150Pa For Medium To Larger Homes
• Vent-Axia Connect Smart App Control For Simple User Adjustment And Commissioning
• Approved Document F Aligned Commissioning Wizard For Installer Confidence
• RF868, Wi-Fi And Bluetooth Low Energy 4.2 Connectivity For Flexible Wireless Control
• Integral Humidistat For Automatic Moisture Responsive Ventilation
• Fully Automatic 100% Summer Bypass With Evening Fresh And Night Time Fresh Functions
• Vertical And Horizontal Spigot Options For Space-Saving Installation
• ISO 60% Coarse (G4) Filters Supplied As Standard With Optional M5 And F7 Filtration
• Left Or Right Hand Spigot Configuration Programmable During Commissioning
• 200mm Spigot Diameter For Compatible Duct Connections
• Height: 881mm
• Width: 728mm
• Depth: 608mm
• Weight: 50kg
