The Greenwood Airvac Unity CV2GIP is a near silent, continuously running dMEV fan. Designed to be installed in bathrooms, en-suites, kitchens and all other types of wet rooms, CV2GIP can be both wall or ceiling mounted. CV2GIP is System 3 (dMEV) compliant meaning installation removes requirements for higher background ventilation sources such as window vents. A short 68mm spigot means that the fan can also be installed in shallow ceiling voids.
Quiet, Discreet & Powerful - Unity CV2GIP operates at a sound level of just 10dB(A) and benefits from a smooth, circular design and clean white finish meaning it is virtually unnoticeable in both operation and aesthetic.
The fan also benefits from a mixed flow backward curved impeller which increases performance whilst lowering energy consumption to as low as just 1.1 Watts. CV2GIP is designed to achieve Guaranteed Installed Performance (GIP) to comply with building regulations.
TimerSMART™ - CV2GIP features Greenwood's intelligent TimerSMART™ overrun timer which helps to reduce heat and energy loss. TimerSMART™helps to deliver effective ventilation by detecting the total time of occupancy to determine how long the fan runs for, rather than using pre-defined sets of time sets which may not be suitable.
HumidiSMART™ - Greenwood's HumidiSMART™ automatic humidity sensor reacts only to excess humidity from sources such as showers and baths. This means that it does not waste energy on background humidity that fluctuates throughout the seasons.
CommisionSMART™ - CommisionSMART™ removes the need for fiddly dip switches and instead provides a smart touch pad which enables quick and simple fan configuration. Installers can set up room type, boost and trickle speeds and controls such as the humidity and timer all from one, simple to use touch pad. Using + and - buttons, installers are also able to increase or decrease the speed of the fan in 1l/s increments to suit the installation.
To further decrease installation times the fascia also benefits from a "twist-lock" feature which allows for easy removal. The inside screws can be loosened but will remain in place thanks to an innovative "stay open" hinge for easy wiring access.
Compliant - CV2GIP complies with System 3 (dMEV), the Low Voltage Directive, EMC Compaitibility Directive, is CE and UKCA marked and has UKAS accreditation.
Key Features of Greenwood Unity CV2GIP Fan Include:
- Suitable for Installation in Any Room
- Can be Wall or Ceiling Mounted
- Near-Silent Operation
- Discreet Design
- SMART Humidistat - Reduces Energy Wastage
- SMART Timer - Reduces Energy Wastage
- SMART Touchpad - For Quick & Efficient Installation
- Highly Energy Efficient - Using as Little as 1.1 Watts
- Removes the Need for Large Ducting Networks
- Ideal for Shallow Ceiling Voids
- Can Be Installed In Zones 1 and 2
- Patented "Twist and Lock" Fascia and "Stay Open" Hinge for Fuss-Free Maintenance
- Overall Diameter: 199mm
- Noise Level: 10dB(A) at Trickle Speed
- Airflow Performance: Trickle: 8l/s (max) Boost: 13l/s (max)
- IP Rating: IPX4 Ceiling, IPX5 Wall
- Max Duct Run: 6m
- Finish: White Satin
- Voltage: 220v-240v
- Weight: 1KG
- Power: 1.1w min - 5.4w max
- Spigot Dimension: 100mm
- 2 Year Guarantee
