BG AFDD RCBO 10A B Curve Single Pole 6kA CURAFDB10A

BG Fortress CURAFDB10A — 10A B Curve Type A AFDD + RCBO (Arc Fault Detection Device, 30mA, 6kA)

The BG CURAFDB10A is a 10A B-curve AFDD with integrated Type A RCBO, delivering the highest level of circuit and fire protection available for domestic and light-commercial installations. It detects dangerous arcing faults—a major cause of electrical fires—that standard MCBs, RCDs and RCBOs cannot identify, including series arcs, parallel arcs and arcing to earth.

By combining AFDD, overload protection, short-circuit protection and 30mA Type A residual-current protection into a compact single-module device, the CURAFDB10A is ideal for socket circuits, lighting, ring finals, and cable routes vulnerable to damage.

AFDD technology continuously monitors circuit waveforms, identifying arc signatures arising from:

Loose or damaged cable terminations

Crushed or degraded cables

Rodent-damaged wiring

Overstressed conductors and failing insulation

The device disconnects the circuit before an electrical fire can develop, making it a critical upgrade for enhanced building safety.

The CURAFDB10A incorporates a complete RCBO, delivering:

30mA Type A RCD protection detecting AC and pulsating DC leakage

Overload and short-circuit protection

Fast, safe disconnection of hazardous currents

This ensures full protection for socket outlets, appliance circuits and areas with increased fire risk.

Compact, Installer-Friendly Design

35mm DIN rail mounting

Positive contact status indication

Terminal capacity from 1–25mm²

High endurance: 4000 electrical / 20,000 mechanical operations

Its slim profile makes AFDD upgrades possible without requiring additional consumer-unit space.

Key Features of the BG AFDD RCBO 10A B Curve Include:

• 10A B-Curve Arc Fault Detection Device with Integrated RCBO
• Detects Series & Parallel Arcing Faults That Standard Devices Cannot
• Combined Overload, Short-Circuit & 30mA Type A Earth-Leakage Protection
• Single-Module 18mm Design Fits BG Fortress Consumer Units
• Reduces Fire Risk from Damaged, Crushed or Degraded Cables
• Positive Contact Status Indicator for Clear Circuit Status
• 6kA Breaking Capacity
• Terminal Capacity 1–25mm² with Secure Torque Settings
• 4000 Electrical / 20,000 Mechanical Operations
• Suitable for Socket Circuits, Radials & General-Purpose Installations
